AT88SC25616C
12.
12.1.
Password Verification
Passwords may be used to protect read and/or write access of any user zone. When a valid password is presented, it
is memorized and active until power is turned off, unless a new password is presented or RST becomes active. There
are eight password sets that may be used to protect any user zone. Only one password is active at a time, but write
passwords give read access also.
Authentication Protocol
The access to a user zone may be protected by an authentication protocol. Any one of four keys may be selected to
use with a user zone.
The authentication success is memorized and active as long as the chip is powered, unless a new authentication is
initialized or RST becomes active. If the new authentication request is not validated, the card loses its previous
authentication and it should be presented again. Only the last request is memorized.
Note :
Password and authentication may be presented at any time and in any order. If the trials limit has been
reached (after four consecutive incorrect attempts), the password verification or authentication process will not
be taken into account.
Figure 13.
Password and Authentication Operations
Device (Card)
Host (Reader)
Card Number
VERIFY A
COMPUTE Challenge B
Challenge B
VERIFY RPW
DATA
Checksum (CS)
VERIFY WPW
VERIFY CS
AUTHENTICATION
READ ACCESS
WRITE ACCESS
COMPUTE Challenge A
Challenge A
VERIFY B
Read Password (RPW)
VERIFY CS
Write Password (WPW)
DATA
CS
Write DATA
13
5017KJS–SMEM–08/09
